tds process solution
tds intelligent dry cleaning machine is tianjin meiteng technology co. ltd is a self-developed intelligent coal gangue separation equipment, is subversive innovation mineral processing technology of more than 100 years with the same.
tcs system solution
tcs is researched and developed with patent by meiteng. it is the up-to-date renovation for the coarse slime separation in the coal processing industry. it brings the technical breakthrough from batch discharging to continuous discharging.
detector of slurry (dsa)
pulp ash content on-line analyzer (dsa) is developed by meiteng, which utilizes optical ash detecting ash content value. dsa can switch to test flotation feed, clean coal and tailing, and transmit data to system in whole produce process.
ash detector of x-ray (dxa)
dxa is an equipment that establish relational model between attenuation of x-ray which penetrate the coal flow and the ash content of coal flow. based on real-time calculation, dxa realize the on-line detection of coal ash.
intelligent coal wash plant solution
intelligent coal wash plant is based on traditional industry automation to utilize internet, data analysis, cloud calculation technologies to realize connections between person and machine, and intelligent operation process control.
the test results are as follows: the average coal content of ra in the 50mm lump coal product is 2.34%. the average coal content of ra in -50mm lump coal products is 2.25%, and the average coal content of 5% in stone belt after selection is 1.84%.
01lingxin tds project
in this project tds used for 200-70(50)mm lump coal preparation. and this one is a three product tds. tds works with dense medium vessel (dmv) to realize 200-6mm preparation. reject material from tds will be ejected to far-end chute, lump coal fall down directly into near-end chute, and middlings be ejected with relatively less energy, to middle position chute.
02haerwusu project (three product)
the project locates in dalad banner baotou city of inner mongolia. one tds10-100 is used to improve coal quality for lump coal by the way of ejecting coal, which has been in operation in december 2017.
03jinke’er tds intelligent dry separation project
the project is in shanxi province, which is a pithead coal preparation plant with 1.8mt/a. tds replace existing hand cleaning process for the existing 2# separation plant. one tds18-305 was used for the project which has been run in august 2017.
04huashengrong coal mine tds intelligent coal separation project
tds intelligent dry separation project for pingshang coal mine of shanxi jincheng antracite mining coal group.
05pingshang tds intelligent dry separation project
the project is located in shanxi province in 2016, which is a 10mt/a capacity coal mine. 100mm lump coal is separated by a tds18-305 instead of hand cleaning.
06zhozhuang tds intelligent dry separation project
xiegou tcs intelligent coarse slime separation project of shanxi xishan jinxing energy co. ltd.,
07xiegou tcs intelligent coarse slime separation project
long gu tcs intelligent coarse slime separation project
08long gu tcs intelligent coarse slime separation project
